The long title is to hep people when they search.


On to it The full suspension review of every piece that i got and have.



Firstly id like to say SpeedFiends "JdmK20a2" is the best site sponser on here. The prices he gave me were considerably lower than competitors and ebay... He even sent them on 2 day delivery.. I highly reccomend him.

First off

Password Jdm 2 pt rear strut bar.




The fit and quality was excellent. Very nice welds and construction. However as strong as password says the bar is i can phyically flex the bar just a little bit.. That was not the case with my neuspeed
During the individual test i felt a slight difference in slalom like turns (quck lefts and rights strung together)

I felt no difference during low or high speed turning

Overall i am happy with it but for what its worth i would have gone with the weapon r x brace..


ASR (A-spec Racing ) rear tie bar/brace


The brace is very heavy and solid.. I got the newer design the one with the engraved lettering.. If you hit someone with this they are getting knocked out

I installed it with out much problem.. my stock control arms were acting bitchy though and didnt want to line up .. That always happens .

Anyway. I tested the tie by its self and felt nothing.. I didnt feel any difference at all during turns high speed cornering or slalom.
Imo this is probally the best lower tie bar you can buy...And if i didnt feel anything with this one i doubt you will feel anything with cheaper smaller ones...IE , skunk 2, dc sports, spoon, meagan. I mean this bar is solid and bolted to the subframe in 4 places as opposed to 1.


I didnt expect much however.


ASR + CTR 22mm sway bar, With energy bushings (compared with a stock 13 mm si bar)


I felt minimal difference in slalom like movments at lower speeds.. I believe the si bar did a decent job of handling this. Quick jerk movments i felt a bit less body roll.. I didnt have much to begin with though

35 mph tight turns were a dream.. I found my self turning wayy to early several times since i did not realize the potential of the bar. It really helps pull the car through turns at higher speeds.

At high speeds i can feel the car have considerably less body roll. at 60 - 85 mph the car is still level even on an offramp. The rear tires begin to slide out as oversteer begins.. This means the tires have become the weakest link in the suspension now

All those people who talk about the car being a completely new car and you will have to learn how to drive again either had shitty suspension before and/or just act like an asshole on the streets on a regular basis.

You really only notice the difference on the street when you are acting like an ass and going 75 on an on/off ramp.

I am worried about my si endlinks since they look at tad worn. I plan to upgrade to the blox endlinks.. i am also glad i sprung the extra money for the energy bushings.

I highly recomend the asr/ctr sway bar combo for the auto-x ers... I recommend those who want to do drag and normal street driving stick with the si bar and or gsr bar. 13/14 mm


·
Registered
Joined
·
46 Posts
Discussion Starter · #2 ·
NRG H brace



Very nice design....Clean ass welds, Almost too perfect of a fit.. I bit too lightweight
Plenty of ground clearance.. I am already very low and it only took about an inch from my under car clearance.



clean welds


As for performance

I am very pleased with this brace.

I felt a slight increase in steering response during slalom movments.
Nothing different in high speed cornering, nothign in mid speed turns.

I got several unexpected benifits though.. Bumps on the road such as railroad tracks and potholes dont hit as hard anymore.. Wheel hop is just about completly gone.. I can launch the car higher now. Shift shock was deacrease tremedously.. Personally i dont do that "ease into a shift balance the clutch and gas stuff" during 2nd and up. As a result my car jerks all the time when i shift and my passenger always goes flying. This surprisingly helped that alot . Its alot smoother now..

You know how when your in first gear and your going too slow and the car is sort of jerking back and forth but still going forward? That doesnt happen anymore which is nice.. I dont have to hold in the clutch while going like 2 mph.



Im tired of typing ill update this later and finish it later


·
Registered
Joined
·
999 Posts
I highly recomend the asr/ctr sway bar combo for the auto-x ers... I recommend those who want to do drag and normal street driving stick with the si bar and or gsr bar. 13/14 mm

the ASR brace is illegal in ST AND SP classes....

but good reviews


·
R2.....Zap Balls
94 Ex coupe
Joined
·
5,186 Posts
Nice write up and pics :TU:. I was wondering about the h brace, good to see didn't take too much ground clearance, I don't have much to give up myself :lol:.


·
Registered
Joined
·
177 Posts
I actually just ordered an H brace, so i'm glad to hear good things about it. My EX has no rear sway bar, so i think i'll get one like that. You say the ASR brace is rubbish 4 performance? Great write-up on the installs.


·
Registered
Joined
·
5,015 Posts
nice write up. why did you go woth the NRG h-brace instead of megan?

when I got an hbrace I went with megan since it has another extra cross brace. I notices the same exact things as you when I installed my h-brace.

NH roads POWN me lol


·
Registered
Joined
·
1,036 Posts
Very good write up. I'm going to look into some of that stuff. Thanks.


·
Registered
Joined
·
41 Posts
I was toying with the idea of an H or X brace for the front. I had to remove my rear lower tie bar when I put my exhaust on (damn under axle HKS), didn't notice any difference there. Also nice to have an idea on how my car will react with the CTR rear sway bar I have. Thanks for the good write up.


·
Registered
Joined
·
5,015 Posts
I still think the megan H brace is better due to the fact that it has an extra cross bar.....

to me it seems like the NRG would flex more in the section that ties onto the unabody then the megan.


·
Registered
88 CRX
Joined
·
1,846 Posts
I still think the megan H brace is better due to the fact that it has an extra cross bar.....

to me it seems like the NRG would flex more in the section that ties onto the unabody then the megan.
I just tried to give you rep for having 1337 posts, but I can't :-(


·
Registered
Joined
·
46 Posts
Discussion Starter · #17 ·
scraped the h brace for the first time today.. didnt hit too hard.. it was my fault cause i was driving irradically..


·
Registered
Joined
·
5,015 Posts
scraped the h brace for the first time today.. didnt hit too hard.. it was my fault cause i was driving irradically..
Ive smacked mine at about 85mph.... still fine.


·
669AWHP
98 Chevy Tahoe
Joined
·
1,234 Posts
very nice write up and very help! rep from me. i ordered one and all the strut bars with the c-piller. i figured y buy one when u could get them all and would work better altogether. plus i got the h brace to help the wheel hop b4 a axle breaks and i ordered traction bars too.
